XPON 1GE ONU 2100M 1GE XPON GPON EPON ONU OEM Type-C Power
SPECIFICATIONS: XPON 1GE ONU
| ITEM | PARAMETER | |
| Interface
| PON Interface | 1 XPON Optical Interface, Meet Class B+ Standard, Upstream 1.244Gbps, Downstream 2.488Gbps, SC-UPC Single-mode Fiber, Split Ratio 1:128, Transmission Distance 20KM |
| User Ethernet Interface | 1*10/100/100M Auto-negotiation, Full/Half Duplex Mode, RJ45 Connector, 100m Distance | |
| Power Interface | 5V Type-C Power Supply | |
| PON Optical Parameter | Wavelength: Tx 1310nm, Rx 1490nm, Tx Optical Power: 0.5~+5dBm, Rx Sensitivity: -27dBm, Saturation Optical Power: -8dBm, Connector Type: SC-UPC, Optical Fiber: 9/125um Single-mode Fiber | |
| Performance Parameters | Data Transmission Parameter | Packet Loss Ratio: <1*10E-12, Latency: <1.5ms |
| Gateway | Router Mode Supports, PPPoE / DHCP / Static IP, WAN support Router and Bridge mode, WAN support Internet, LAN supports DHCP and Static IP, Support NAT and NAPT | |
| Business Capability | Layer 2 wire speed switching, Support VLAN TAG / UNTAG, VLAN conversion, Support Port-based speed limitation, Support Priority Classification, Support Storm Control of Broadcast | |
| Network Management | Management Mode | Support ITU-T G.984 OMCI, ONU can be remotely managed by OLT, Support Remote management through Telnet or http, Local Management |
| Management Function | Status Monitor, Configuration Management, Alarm Management, Log Management | |
| Indicator | LED Indicator | PWR: Power Up or Down, LOS: Optical Link Status, PON: ONU Registered LINK / ACT: Link Status of Ethernet Interface |
| Physical Features | Shell | Plastic Casing |
| Power | External 5V 1 A Type-C Power Supply, Power Consumption: <2W (FD101HC), <2.3W[FD111HC] | |
| Physical Specifications | Item Dimension: 92mm (L) x 21.5mm (W) x 17mm (H) Item Weight:0.03kg | |
| Environmental Specifications | Operating Temperature: -20 to 70°C Storage Temperature: -40 to 85°C Operating Humidity: 10% to 90% (non-condensing) Storage Humidity: 10% to 90% (non-condensing) |
