Fujikura 35S Fusion Splicer

The 35S cladding alignment fusion splicer is changing the way people splice fiber in small to mid-fiber count applications. This Fujikura splicer debuts a landmark improvement to the fusion splicing process with the ability to prepare and load both fibers simultaneously. The hand-held fiber coating stripper, the SS-05, is capable of stripping two 250 µm coated fibers in the same pass, along with the CT-16 cleaver adapter plate which can likewise accommodate two bare fibers for cleaving. After preparation, the 35S patented sheath clamps enable loading both fibers simultaneously into the splicer with one fiber in each hand. The user can press down on the sheath clamp base to close it while positioning the fiber in the v-grooves. This enables a one handed operation.

Furthermore, the 35S sheath clamps are mechanically linked to the wind protector, so after splicing is finished, opening the wind protector also opens both sheath clamps for quick sleeve positioning and transfer to the tube heater. The 35S tube heater shrinks sleeves much faster than its predecessor with a nominal ~20 second heat time for 60 mm sleeves down from ~26 seconds. The simultaneous fiber preparation capability, automated sheath clamp opening, and a faster tube heater, combine to lower the overall fusion splicing cycle time by ~30% or more.

The 35S continues to benefit the user experience with improvements to fiber placement, battery access, and machine ergonomics. Previously, when using sheath clamps, if the cleaved fiber was accidentally set past the electrode centerline, the machine would send an error and require manual intervention. The 35S will now accept this mistake and reverse the fiber to correct position automatically. With a cube form factor, the 35S is easily transported and operated in space-constrained environments. The adjustable screen can alleviate glare from the sun and adjust with abnormal splicer positions confronted in challenging splice locations.

Backed by the best service team in the industry, the Fujikura 35S is the ideal splicer to use when portability, ruggedness, speed, and reliability are needed. If you’d like to see the 35S capabilities first-hand, please contact us at 1-800-235-3423 to arrange a product demonstration at your earliest convenience.

SUMITOMO TYPE 82C+ FUSION SPLICER

The world’s first AI programmed High Definition Core Aligning fusion splicer

PRODUCT DESCRIPTION

Product Name: Nap Box 8 port Fiber Splitter Box FTTH Insert type Fiber Optic Distribution Box For PLC Splitter

Color: Black

Application:

● Telecom network
● CATV network
● Ethernet network

Options

● 8 ports Nap Box empty, cassette type
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC UPC
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC UPC w/ pigtail
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC APC
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC APC w/ pigtail
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, LCP

ALK-7000
Optical Time Domain Reflectometer

Features:

1. 7-inch HD color touch screen.
2. Finger combine to control curve zoom in, zoom out and move.
3. Multiple test modes.
4. Multiple wavelength modes.
5. OTDR self-testing function.
6. External USB LED light.
7. Document can be exported in PDF format. 8). Event map (event thresholds can be test).

Fujikura 90S+ Fusion Splicer

he Fujikura 90S+ core alignment fusion splicer solves common problems seen in the field—from splicing poor quality legacy fiber to automated equipment maintenance and upkeep. The Fujikura 90S+ can be use in multiple field splicing applications including bend-insensitive fibers in drop cables, long-haul terrestrial and submarine LEAF® fibers, loose buffer fiber, splice-on connectors, and the list goes on. The speed and accuracy of the 90S+ make it suitable for certain production and specialty environments where high output, tight packaging, and low loss requirements are required.
