CCORP 1F, 2F, 4F FTTH FIBER DROP CABLE GJYXCH

Order Now

Call for Price

GJYXCH 1F/2F/4F Outdoor Drop Cable (1.0mm) is a flat, durable fiber optic cable designed for FTTH outdoor use. It features 1, 2, or 4 single-mode fibers and a 1.0mm galvanized steel strength member, offering strong tensile performance, UV resistance, and reliable signal transmission in demanding outdoor environments.

Features

Fiber Count Options: Available in 1, 2, or 4 single-mode fibers to support various FTTH deployment needs.

Central Strength Member: Equipped with a 1.0mm galvanized steel wire for enhanced tensile strength and durability.

Flat and Compact Design: Simplifies installation in aerial, duct, or wall-mounted setups, especially in tight or limited spaces.

UV-Resistant Outer Sheath: Ensures long-term reliability in outdoor environments exposed to sunlight and weather.

LSZH Jacket: Flame-retardant, low-smoke outer sheath enhances safety and environmental compliance.

Bend-Insensitive Fiber: Uses G.657A1/A2 fiber for better performance in tight bends or complex routing paths.

Lightweight and Flexible: Easy to handle, transport, and install with reduced labor costs.

Wide Application: Ideal for last-mile fiber connections in FTTH networks for homes and small businesses.

Field-Termination Friendly: Compatible with pre-terminated connectors and field-installable solutions.

Standards Compliance: Meets ITU-T G.657A1/A2 and RoHS standards for quality and environmental safety.

CCORP 1F, 2F, 4F FTTH FIBER DROP CABLE GJYXCH

is a high-quality flat fiber optic cable specifically engineered for FTTH (Fiber to the Home) outdoor drop applications. It is available in 1, 2, or 4 single-mode fiber configurations, making it an ideal solution for connecting individual users or small buildings to the broader optical distribution network. This cable features a 1.0mm galvanized steel wire as the central strength member, providing solid tensile strength and mechanical stability during aerial spans, wall mountings, or duct installations. Its flat, lightweight structure allows for quick and efficient deployment while minimizing space usage. The outer jacket is made of UV-resistant and weatherproof LSZH (Low Smoke Zero Halogen) material, ensuring long-lasting durability in harsh outdoor environments. The cable is also fire-retardant and environmentally safe, meeting modern safety and environmental standards. It typically uses bend-insensitive G.657A1/A2 fiber, allowing for tight routing without significant signal degradation. Designed for direct termination or use with pre-terminated connectors, the GJYXCH 1F/2F/4F (1.0mm) drop cable provides a cost-effective and reliable solution for last-mile FTTH connections in both residential and small enterprise applications.

General

The specification covers the construction and properties of flat optical fiber cable.
The cable shall be used for aerial, duct, or fixed by the wall installed.
The optical fiber which is used in the cable is also in compliance with ITU-T Rec.G.657A.
The cable generally meets any latest relevant ITU-T Recommendation or better.
The single mode fiber shall operate in 1310nm and 1550nm.
The cable could serve for 10 years without any significant deterioration.

Cable Cross-section

Airblown Fiber Optic Cable June 13, 2025 Philippines

Cable Structure and Parameter

ITEM	CONTENTS	UNIT	VALUE
Optical Fiber	Model number	/	G657A1
	Number	/	1	2	4	8
	Color	/	Blue, Orange, Green, Brown
Strength Member	Material	/	Steel wire
	Diameter	mm	0.45
Messenger wire	Material	/	Galvanized Steel Wire
	Diameter	mm	1.0
Outer Jacket	Diameter	mm	5*2		5.2*2
	Material	/	LSZH
	Color	/	Black
Tensile Performance	Short Term	N	600 (fiber strain≤0.4%)
	Long Term	N	300
Crush	Short Term	N/100mm	1000
	Long Term	N/100mm	300
Cable weight (Approx.) ±10%		kg/km	20
