C-CORP CCTIP08 TUNER to IP Gateway with DVB-S/-S2 Input
Order Now
Call for Price
The CCTIP08 Tuner to IP Gateway is a device designed to convert DVB-S/S2 satellite signals into IP streams for digital distribution systems. While specific details about the CCTIP08 model are limited, similar products in the market offer comprehensive features for DVB to IP conversion.
Key Features
Input Options: Supports DVB-S and DVB-S2 tuners, allowing for flexible satellite signal reception.
IP Output: Capable of outputting multiple SPTS (Single Program Transport Streams) or MPTS (Multiple Program Transport Streams) over IP, facilitating efficient content distribution.
ASI Input/Output: Includes ASI (Asynchronous Serial Interface) inputs and outputs for integration with other broadcast equipment.
Multiplexing and Modulation: Supports multiplexing and modulation functions, enabling the creation of custom transport streams.
PID Remapping and PCR Adjustment: Allows for PID (Packet Identifier) remapping and precise PCR (Program Clock Reference) adjustments to ensure stream integrity.
PSI/SI Table Management: Facilitates the generation and editing of PSI (Program Specific Information) and SI (Service Information) tables, essential for DVB compliance.
Web-Based Management: Features a user-friendly web interface for remote monitoring and configuration.
Redundant Power Supply: Optional redundant power supply for enhanced reliability in critical applications.
The C-CORP CCTIP08
is a device used for converting satellite signals from a satellite dish or other satellite reception equipment into IP streams over UDP or RTP. It can seamlessly integrate with existing IP networks and allow for wider accessibility and reach of satellite TV channels and other multimedia content.
FEATURES:
1. Equipped with 8 DVB-S/-S2 independent transponders
2. Output IP streams in 8 MPTS or 256 SPTS
3. Supports CA PID filtering, remapping and PSI/SI editing
4. Select desired services to stream out
5. Graphic user interface for easy configuration
6. Rack and wall mountable.
TUNER INPUT
Input Connector: 8 * RF inputs @75Ω
Input Level: 40 ~ 90 dBμV
Tuner Number: 8 Transponders
Frequency Range: 950 ~ 2150 MHz
Demodulation: DVB-T, DVB-T2, DVB-C
DC Remote Power at RF Input: 13V/ 18V/ 22kHz/DiSEqC 2.0 A-B-C-D
IP OUTPUT
Output Connector: 1 * 1000 Mbps port
Transport Protocol: UDP, RTP
Output Transport Stream: MPTS * 8 or SPTS*256
Broadcasting Mode: Unicast and Multicast
MULTIPLEXING
Table Supported: PSI/SI
PID Processing: Pass-through, Remapping, Filtering
GENERAL
Input Voltage: 90 – 264VAC, DC 12V 2A
Test Point: -20dB relative to input port
Power consumption: Less than W
Dimension: (WxHxD) 482*44*260mm
Net Weight: KG
Language: Chinese / English
