Active V-Groove Alignment i4 is a high-precision fiber alignment technology used in fusion splicing equipment. It actively adjusts fiber positions using real-time optical feedback to ensure optimal core-to-core alignment, delivering low splice loss and high reliability—ideal for FTTH and single mode fiber applications.

FEATURES

• Real-Time Core Alignment:

  • Uses image processing and optical feedback to actively align fiber cores with high precision.

• Low Splice Loss:

  • Ensures minimal insertion loss, even with fibers that have slight geometric differences or core offsets.

• Supports Multiple Fiber Types:

  • Compatible with standard single-mode (SMF), bend-insensitive (G657A1), and multi-mode fibers.

• Fast and Accurate Splicing:

  • Optimized for speed and precision, reducing alignment and splicing time.

• Enhanced Reliability:

  • Delivers consistent performance across a variety of field conditions and fiber types.

• User-Friendly Interface:

  • Often integrated into intuitive fusion splicer systems for easy operation and monitoring.

• Compact and Durable Design:

  • Suitable for both field and lab environments, offering portability without compromising performance.

• Automatic Fiber Detection:

  • Identifies fiber type and adjusts alignment settings accordingly for optimal results.

PRODUCT DESCRIPTION

Product Name: Nap Box 8 port Fiber Splitter Box FTTH Insert type Fiber Optic Distribution Box For PLC Splitter

Color: Black

Application:

● Telecom network
● CATV network
● Ethernet network

Options

● 8 ports Nap Box empty, cassette type
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC UPC
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC UPC w/ pigtail
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC APC
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, SC APC w/ pigtail
● 8 ports Nap Box w/ 1×8 Splitter, cassette type, LCP

Fujikura 90S+ Fusion Splicer

he Fujikura 90S+ core alignment fusion splicer solves common problems seen in the field—from splicing poor quality legacy fiber to automated equipment maintenance and upkeep. The Fujikura 90S+ can be use in multiple field splicing applications including bend-insensitive fibers in drop cables, long-haul terrestrial and submarine LEAF® fibers, loose buffer fiber, splice-on connectors, and the list goes on. The speed and accuracy of the 90S+ make it suitable for certain production and specialty environments where high output, tight packaging, and low loss requirements are required.
